Chipset ：RTL8723BU |
|||||
|
Bluetooth instructions： |
|||||
|
Bluetooth version |
V4.0 |
||||
|
type |
USB1.1/USB2.0 |
||||
|
Transmission distance |
10 meters |
||||
|
RF power |
10dBm（MAX） |
||||
|
Antenna gain |
2dBi |
||||
|
transfer speed |
3M/S |
||||
|
current |
100mA – 200mA(BT+WIFI) |
||||
|
Support operating system |
WIN 7/WIN8/10 system |
||||
|
WiFi instructions： |
|||||
|
Supported standards |
IEEE 802.11n、 IEEE 802.11g、IEEE 802.11b、CSMA/CA with ACK |
||||
|
transfer speed |
150Mbps |
||||
|
Frequency |
2.4～2.4835GHz |
||||
|
Working channel |
1-14 |
||||
|
Modulation |
|
||||
|
Transmission rate |
|
||||
|
Receiving sensitivity |
130M： -65dBm@10% PER; 108M：-65dBm@10% PER; 54M：-65dBm@10% PER; 11M：-87dBm@8% PER;
|
||||
|
Transmission distance |
Up to 100 meters indoors and 200 meters outdoors (depending on the environment) |
||||
|
RF Power |
16dBm（MAX） |
||||
|
Antenna gain |
2dBi |
||||
|
Spread spectrum technology |
DSSS（Direct sequence spread spectrum） |
||||
|
current |
100mA – 200mA(BT+WIFI) |
||||
|
Support operating system |
Windows 2000/XP/Vista/WIN 7/WIN 8/10/MAC OS system |
||||
|
Use environment |
|
||||
